Product Details:
|
| Product Name: | Combined Upright Refrigerated Display Case | Temperature: | 2 ~ 10 ℃ / -18 ~ -22℃ |
|---|---|---|---|
| Comprssor: | Panasonic / Tecumseh | Product Size: | 2500*1200*2000mm |
| Side Panel: | 80*1200*2000mm | Refrigerant: | R404A |
| High Light: | R404A Upright Refrigerated Display Case,CE Upright Refrigerated Display Case |
||
Supermarket Refrigeration Equipments Combined Upright Refrigerated Display Case
Features:
Temperature range: 2~ 10℃ for top glass door fridge. Besides, it also can be made to -18 ~ -22℃ if you need.
-18 ~ -22 ℃ for bottom island freezer.
Top glass door fridge: three layer tempered glass with aluminum door frame and handle. Self closing type.
Bottom island freezer: sliding glass door on the top
Refrigeration system: high quality compressor, pure copper evaporator and condenser, cooling more fast and even, longer service life.
Insulation 50mm thickness: 50mm thickness CFC free, high density fand energy saving in all cabinets
Electronic themostat and LED digital Temperature display for accuracy and easy reading
Specifications:
| PRODUCT NAME | Combined Upright Refrigerated Display Case |
| Model number | SGD-2500FDM |
| Product dimension (mm) | 2500(w) x 1200(d) x 2200(h) |
| Package dimension (mm) | 2600(w) x 1200(d) x 2200(h) |
| Temperature range | 2°C~10°C / -18~ -22℃ |
| Cooling system | Ventilated |
| Voltage | 220V/50Hz;220V/60Hz; 110V/60Hz; |
| Compressor | Panasonic / Tecumseh |
| Refrigerant | R410A/ 404A |
| Shelf | 2-tier adjustable + a base, total 3tier |
| Light | T5 |
| Evaporator | 100% copper |
| condenser | 100% copper |
| thermostat | Digital |
| wheel | yes |
| Ambient temperature | Under 35°C |
| Warranty | 12 months spare parts. |
More sizes for option:
| Model |
Product Dimension(mm) (W*D*H) |
Temperature (℃) |
Remark |
| SGD-1250FDM | 1250*1200*2000 | 2~10/-18~ -22 | 2 doors |
| SGD-1875FDM | 1875*1200*2000 | 2~10/-18~ -22 | 3 doors |
| SGD-2500FDM | 2500*1200*2000 | 2~10/-18~ -22 | 4 doors |
| Side panel(2 pcs) | 80*1200*2000 | 2~10/-18~ -22 | / |
Note: this supermarket refrigerated display case can be combined by several parts as one whole unit.
For example: if you need 5 doors: then the length will be 1250+1875+80=3205mm for total
if you need 6 doors: then the length will be 1875+1875+80=3830mm for total
Product details:
FAQ:
Q1: How many days will supermarket refrigeration equipments sample be finished ? How about the mass production ?
For the items we have on stock, we can send you the sample once getting your sample fee .
The mass production time depend on the ordered quantity, as usual, it needs 15-20 days.
Q2: Can I have our logo or company information on the supermarket refrigeration equipment ?
Yes , of course , we are the OEM factory and can make based on your request .
